Champ VMVL LED and PVML LED with Emergency Back-up Battery

Certifications and compliances

NEC & CEC

VMVL only:

• Class I, Division 2, Groups A, B, C, D
• Class I, Zone 2
• Class II, Division 1, Groups E, F, G
• Class III
• Simultaneous Presence


VMVL & PVML:

• Wet locations, Type 4X, IP66

UL standards

VMVL only:

• UL844 – Hazardous (Classified) Locations

VMVL & PVML:

• UL1598 – Luminaires, UL1598A – Marine
• UL924 – Emergency Luminaire

CSA standard

• CSA C22.2 No. 137

• Integral battery back-up provides 90 minutes of emergency lighting in the event of a power loss
• Five models from 3,000 lumens to 11,000 lumens for areas with mounting heights of 8-20 feet
• Die cast aluminum heat sink increases surface areas and improves airflow, optimizing both LED and driver life; the VMVL LED has a rated life of 60,000 hours at 55°C ambient, and its economic life ranges from 7 to 20 years
• Energy-efficient technology – up to 77% energy savings over HID fixtures
• Shock- and vibration-resistant solid state luminaires have no filaments or glass components that could break – greatly reduces the risk of premature failure
• Custom Type V, Type III and Type I optics distribute the light where it is needed most and can help reduce the number of fixtures required for certain lighting applications
• Contractor-friendly VMVL LED utilizes the same mounting modules as our legacy HID luminaires, simplifying installation and reducing costs in retrofit projects
• Mounting styles – pendant mount; cone pendant mount; flexible pendant mount; ceiling mount; wall mount; stanchion 25° mount; stanchion straight mount
• Cool white standard (5000K, 70 CRI); warm white (3000K, 80 CRI) and neutral white (4000K, 80 CRI) optional
• Instant illumination and restrike
• Cold temperature operation/no warm-up required
• Contains no mercury or other hazardous substances

• Lamp housing and adapter – die cast aluminum with Corro-free epoxy powder coat
• Lens – heat- and impact-resistant glass
• Gaskets – silicone
• External hardware – stainless steel
• Factory sealed, no external seals required
