TVS R1320

This model flows 1320 cubic centimeters of air in one rotation and can be used in single boost applications.  It is a good option for increasing performance in 3.0 to 4.5 liter engines.

The key advantage of the R-Series is to deliver peak efficiencies at high pressure ratios and high speeds providing fast response and available boost when exhaust gas energy is low.

Volume per rotation
1,320 cubic centimeters
Installation
Single
Outlet design
Axial or radial

核心功能

  • Integrated electromagnetic clutch compatable
  • 4 lobe rotor design with 160 degree twist

Learn more about TVS technology

TVS has several innovative features that make it reliable and efficient.
productfamily.specification

Key Specifications

Performance Unit Value
Max Mass Flow Rate at PR 1.0*  kg/hr 1,867
Max Pressure Ratio   2.5
Max Rotor Speed  rpm 20,000
Max Input Power  kW 73
Max Outlet Temperature  Celsius 160
Max Outlet Pressure Bar 2.5
Pulley-to-rotor speed ratio   1:1 or 2:1

*Standard inlet condition at 100 kPa, 25°C
